Parámetro principal
- Bomba dosificadora mecánica GB flow range:240-1800LPH@50Hz/288-2160LPH@60Hz
- Bomba dosificadora mecánica GB pressure range: 3-10 Bar
- Bomba dosificadora mecánica GB power: 380V@50Hz on standard, others on request
- Bomba dosificadora mecánica GB material: CLORURO DE POLIVINILO; PVDF; SS304; SS316
| Modeloo | 50Hz | 60Hz | Presión | Diafragma (mm） | Energía | |||||
| Caudal (LPH) | Caudal (GPH) | GDS | Caudal (GPH) | Caudal (LPH) | GDS | BAR | PSI | |||
| GB240/1.0 | 240 | 63 | 48 | 75 | 288 | 58 | 10 | 145 | 148 | 0.75KW |
| GB320/1.0 | 320 | 84 | 101 | 384 | 10 | 145 | ||||
| GB500/1.0 | 500 | 131 | 96 | 157 | 600 | 115 | 10 | 145 | ||
| GB680/0.7 | 680 | 179 | 214 | 816 | 7 | 102 | ||||
| GB760/0.5 | 760 | 200 | 144 | 240 | 912 | 173 | 5 | 73 | ||
| GB1000/0.4 | 1000 | 264 | 315 | 1200 | 4 | 58 | ||||
| GB1200/0.4 | 1200 | 315 | 96 | 379 | 1440 | 115 | 4 | 58 | 185 | 1.1KW |
| GB1600/0.3 | 1600 | 421 | 144 | 505 | 1920 | 173 | 3 | 44 | ||
| GB1800/0.3 | 1800 | 476 | 571 | 2160 | 3 | 44 | ||||
Conexión
| Modeloo | CLORURO DE POLIVINILO | PVDF | SS304/316 | |||||
| GB240-GB1000 | DN25 unión de pegamento | CR 1"F | CR 1"F | |||||
| GB1200-GB1800 | DN40 unión de pegamento | Radiocontrol 1.5"F | Radiocontrol 1.5"F | |||||
